| SN |
OEM Part No |
Part No. |
Descriptions |
Qty |
| 1 |
G116903 |
116903 |
Rifle Nut |
1 |
| 2 |
G116910 |
116910 |
Valve Spring |
2 |
| 3 |
G116973 |
116973 |
Retainer Pin |
1 |
| 4 |
G116971 |
116971 |
Retainer |
1 |
| 5 |
G110116 |
110116 |
Elastic Pin (ø10 X 45) |
2 |
| 6 |
G116943 |
116943 |
Retainer Bushing |
1 |
| 7 |
G116914 |
116914 |
Air Inlet Stem |
1 |
| 8 |
G116906 |
116906 |
Rotation Chuck |
1 |
| 9 |
G116918 |
116918 |
Chuck Nut |
1 |
| 10 |
G116905 |
116905 |
Chuck Bush |
1 |
| 11 |
G116907 |
116907 |
Pawl |
4 |
| 12 |
G116960 |
116960 |
Pawl Plunger |
4 |
| 12.1 |
|
|
Pawl Plunger Modified (steel) |
4 |
| 13 |
G116927 |
116927 |
Pawl Spring |
4 |
| 14 |
G116983 |
116983 |
Guide Bushing Lubricating |
1 |
| 15 |
G116920 |
116920 |
Valve Location Pin (ø8 X 28) |
1 |
| 16 |
G116901 |
116901 |
Rifle Bar |
1 |
| 17 |
G116949 |
116949 |
Side Bolt Washer |
2 |
| 18 |
G116965 |
116965 |
Side Bolt Nut |
2 |
| 19 |
G116978 |
116978 |
Front Head |
1 |
| 20-21 |
|
|
|
|
| &23 |
|
|
Intermediate Part Assembly |
|
| 20 |
G116941 |
116941 |
Intermediate Part |
1 |
| 21 |
G116928 |
116928 |
Liner |
1 |
| 1&22 |
|
|
Piston Complete |
|
| 22 |
G116904 |
116904 |
Piston |
1 |
| 23 |
G820001 |
G820002 |
O-ring (ø86 X 3 ) |
1 |
| 24 |
G116976 |
116976 |
Main Valve |
1 |
| 25 |
G116902 |
116902 |
Ratchet Ring |
1 |
| 26 |
G116942 |
116942 |
Water Tube Rubber Bush |
2 |
| 27 |
G116929 |
116929 |
Adapter |
1 |
| 28 |
G116952 |
116952 |
Adapter Coupling |
1 |
| 29 |
G116996 |
116996 |
Cylinder |
1 |
| 30 |
G116921 |
116921 |
Valve Pin |
2 |
| 31 |
G116953 |
116953 |
Back Head |
1 |
| 2,24, |
|
|
|
|
| 30-33 |
|
|
Valve Seat Complete |
|
| 32 |
G116961 |
116961 |
Valve Seat |
1 |
| 33 |
G116970 |
116970 |
Valve Cover |
1 |
| 34 |
G116923 |
116923 |
Side Rod |
2 |
| 35 |
G116908 |
116908 |
Air Tube |
1 |
| 36 |
G116999 |
116999 |
Muffler |
1 |
|
|
|
Name Plate |
1 |
