SN	OEM Part No	Part No	Description	Quantity
1	3122 0305 00	G3122 0305 00	End Piece	1
2	3122 0159 00	G3122 0159 00	Nut	1
3	0663 9206 00	G0663 9206 00	O-Ring	1
4	3122 0169 00	G3122 0169 00	Nut	2
5	3132 0018 00	G3132 0018 00	Brake Ring	1
6(7-8)	3122 0348 80	G3122 0348 80	Piston Complete	1
7	-	-	Piston	1
8	-	-	Washer	1
9	3122 0167 00	G3122 0167 00	Packing	2
10	3122 0168 00	G3122 0168 00	Washer	1
11	3122 0161 00	G3122 0161 00	Cylinder	1
12	3122 0160 00	G3122 0160 00	Tube	1
13	3115 1194 00	G3115 1194 00	Handle	1
14	0347 6114 00	G0347 6114 00	Hose Clip	2
15	3112 0175 00	G3112 0175 00	Guide Ring	1
16	3122 0176 00	G3122 0176 00	Packing	2
17(18-19)	3122 0177 80	G3122 0177 80	Guide Socket, Com.	1
18	3122 0177 00	G3122 0177 00	Guide Socket	1
19	3122 0178 00	G3122 0178 00	Bushing	1
20	3122 0162 00	G3122 0162 00	Piston Rod	1
21	0333 2174 14	G0333 2174 14	Spring Washer	1
22	3121 5111 00	G3121 5111 00	Foot	1
23	3121 0493 00	G3121 0493 00	Nut	1
24	3122 0306 00	G3122 0306 00	Pin	1
25	3122 0334 00	G3122 0334 00	Liner	1
26	0663 2132 00	G0663 2132 00	O-Ring	3
27	0663 2128 00	G0663 2128 00	O-Ring	3
28	3122 0309 00	G3122 0309 00	Rubber ring	1
29	3122 0371 00	G3122 0371 00	Washer	1
30	0101 1274 00	G0101 1274 00	Pin	1
31	-	-	Data Plate	1
32	-	-	Safety Label	1
