| SN. |
PART NO. |
OEM PART NO. |
DESCRIPTION |
QTY |
| 1 |
G3115 2475 00 |
3115 2475 00 |
Drill Retainer |
1 |
| 2 |
G3115 2068 00 |
3115 2068 00 |
Retainer Pin |
1 |
| 3 |
G0108 1359 00 |
0108 1359 00 |
Slotted Spring Pin (Ø 8 x 32 mm) |
1 |
| 4 |
G3111 0057 00 |
3111 0057 00 |
Rubber Buffer |
1 |
| 5 |
G3111 0056 00 |
3111 0056 00 |
Buffer Plate |
1 |
| 6 |
G3111 0053 00 |
3111 0053 00 |
Front Head |
1 |
| 7 |
G3111 0062 00 |
3111 0062 00 |
Cap Nut |
2 |
| 8 |
G3111 0023 00 |
3111 0023 00 |
Conical Spring |
2 |
| 9 |
G3111 0020 00 |
3111 0020 00 |
Pawl |
2 |
| 10 |
G3111 0066 00 |
3111 0066 00 |
Drill Chuck (Hexagon 22 x 108 mm) |
1 |
| 11 |
G3111 0024 00 |
3111 0024 00 |
Driver |
1 |
| 12 |
G3111 0019 00 |
3111 0019 00 |
Ratchet Wheel |
1 |
| 13 |
G3111 0017 00 |
3111 0017 00 |
Intermediate Part |
1 |
| 14 |
G3111 0050 00 |
3111 0050 00 |
Piston |
1 |
| 15 |
G3111 0015 00 |
3111 0015 00 |
Cylinder |
1 |
| 16 (17-19) |
G3111 0047 80 |
3111 0047 80 |
Cover, Complete |
1 |
| 17 |
G3111 0047 00 |
3111 0047 00 |
Cover |
1 |
| 18 |
G3111 0048 00 |
3111 0048 00 |
Bushing |
1 |
| 19 |
G0108 3241 00 |
0108 3241 00 |
Pin (Ø 4 x 22 mm) |
1 |
| 20 |
G3111 0049 00 |
3111 0049 00 |
Main Valve |
1 |
| 21 |
G3115 2096 00 |
3115 2096 00 |
Throttle Housing |
1 |
| 22 |
G3115 1967 00 |
3115 1967 00 |
Valve |
1 |
| 23 |
G3115 2086 00 |
3115 2086 00 |
Throttle Lever |
1 |
| 24 |
G3111 0044 00 |
3111 0044 00 |
Inlet Nipple |
1 |
| 25 |
G3111 0043 00 |
3111 0043 00 |
Adapter |
1 |
| 26 |
G3000 5825 02 |
3000 5825 02 |
Adapter |
1 |
| 27 |
G3115 1543 00 |
3115 1543 00 |
Hose Nipple (19 mm) |
1 |
| 28 |
G9000 0338 00 |
9000 0338 00 |
Wing Nut |
1 |
| 29 |
G3115 0811 00 |
3115 0811 00 |
Handle Bracket |
1 |
| 30 (31-32) |
G3310 0569 80 |
3310 0569 80 |
Handle, Complete |
1 |
| 31 |
– |
– |
Handle |
1 |
| 32 |
G3310 0572 00 |
3310 0572 00 |
Bushing |
2 |
| 33 |
G0108 1360 00 |
0108 1360 00 |
Pin (Ø 8 x 36 mm) |
2 |
| 34 |
G3111 0061 00 |
3111 0061 00 |
Side Bolt |
2 |
| 35 |
G3000 0121 00 |
3000 0121 00 |
Gasket |
1 |
| 36 |
G3111 0045 00 |
3111 0045 00 |
Flushing Tube |
1 |
| 37 |
G0663 2124 00 |
0663 2124 00 |
O-Ring (Ø 17.3 x 2.4 mm) |
1 |
| 38 |
G3111 0046 00 |
3111 0046 00 |
Plug |
1 |
| 39 |
– |
– |
Data Plate |
1 |
