| GME Ref No. | OEM Part Number | GME Part Number | Description | Qty |
| 1 | 7490 5161 20 | G7490 5161 20 | SHANK ADAPTER | 1 |
| 5 | 3115 2231 00 | G3115 2231 00 | DRILL COLLAR | 1 |
| 10 | 3115 0286 00 | G3115 0286 00 | DOME NUT | 6 |
| 11 | 3115 0287 00 | G3115 0287 00 | WASHER | 6 |
| 17 | 3115 1457 00 | G3115 1457 00 | SIDE BOLT | 1 |
| 18 | 3115 5040 00 | G3115 5040 00 | SIDE BOLT | 2 |
| 20 | 3115 3473 80 | G3115 3473 80 | HYDRAULIC MOTOR | 1 |
| 21 | 3115 0277 00 | G3115 0277 00 | COUPLING | 1 |
| 22 | 3115 2130 00 | G3115 2130 00 | CIRCLIP | 1 |
| 24 | 3115 0327 00 | G3115 0327 00 | GASKET | 1 |
| 25 | 3115 3548 00 | G3115 3548 00 | NUT | 4 |
| 30 | 3115 3451 81 | G3115 3451 81 | ACCUMULATOR INTAKE | 1 |
| 30.01 | 3115 3451 81 20 | G3115 3451 81 20 | DIAPHRAGM COVER | 1 |
| 30.02 | 3115 2697 00 | G3115 2697 00 | DIAPHRAGM HOUSING | 1 |
| 30.03 | 3115 1822 01 | G3115 1822 01 | DIAPHRAGM | 1 |
| 30.04 | 3115 3768 00 | G3115 3768 00 | VALVE | 1 |
| 30.05 | 3115 0263 00 | G3115 0263 00 | PLUG | 1 |
| 30.06 | 0663 6121 00 | G0663 6121 00 | O-RING | 1 |
| 30.07 | 3115 2702 10 | G3115 2702 10 | SCREW | 2 |
| 31 | 3115 3511 81 | G3115 3511 81 | ACCUMULATOR DAMPER | 1 |
| 31.01 | 3115 3511 81 20 | G3115 3511 81 20 | DIAPHRAGM COVER | 1 |
| 30.02 | 3115 2697 00 | G3115 2697 00 | DIAPHRAGM HOUSING | 1 |
| 30.03 | 3115 1822 01 | G3115 1822 01 | DIAPHRAGM | 1 |
| 30.04 | 3115 3768 00 | G3115 3768 00 | VALVE | 1 |
| 30.05 | 3115 0263 00 | G3115 0263 00 | PLUG | 1 |
| 30.06 | 0663 6121 00 | G0663 6121 00 | O-RING | 1 |
| 30.07 | 3115 2702 10 | G3115 2702 10 | SCREW | 2 |
| 35 | 3115 2615 91 | G3115 2615 91 | RETURN ACCUM. | 1 |
| 35.01 | 0147 1483 03 | G0147 1483 03 | SCREW, HEX HEAD | 1 |
| 35.02 | 3115 2615 20 | G3115 2615 20 | TUBE | 1 |
| 35.03 | 3115 2885 00 | G3115 2885 00 | TUBE COVER | 1 |
| 35.04 | 3115 2886 00 | G3115 2886 00 | PIPE | 1 |
| 35.05 | 3115 2889 00 | G3115 2889 00 | PRESSURE SCREW | 1 |
| 35.06 | 0663 2109 37 | G0663 2109 37 | O-RING | 1 |
| 35.07 | 0663 2129 01 | G0663 2129 01 | O-RING | 1 |
| 35.08 | 3115 2618 00 | G3115 2618 00 | END PIECE | 1 |
| 35.09 | 0663 2128 00 | G0663 2128 00 | O-RING | 1 |
| 35.10 | 3115 1926 02 | G3115 1926 02 | DIAPHRAGM | 1 |
| 35.11 | 3115 2617 20 | G3115 2617 20 | PLUG | 1 |
| 35.12 | 9125 6191 00 | G9125 6191 00 | O-RING | 1 |
| 35.13 | 0661 1038 00 | G0661 1038 00 | SEAL WASHER | 1 |
| 35.14 | 3176 6528 00 | G3176 6528 00 | NIPPLE | 1 |
| 35.21 | 3115 2275 00 | G3115 2275 00 | CLAMP | 1 |
| 35.22 | 3115 2276 00 | G3115 2276 00 | HOLDER | 1 |
| 35.23 | 0147 1328 03 | G0147 1328 03 | SCREW, HEX HEAD | 2 |
| 35.24 | 0291 1128 19 | G0291 1128 19 | LOCK NUT | 2 |
| 70 | 3176 6512 00 | G3176 6512 00 | NIPPLE | 2 |
| 71 | 3176 6514 00 | G3176 6514 00 | NIPPLE | 1 |
| 100 | 3115 5042 80 | G3115 5042 80 | FRONT PART COMP | 1 |
| 150 | 3115 5036 60 | G3115 5036 60 | COVER GROUP | 1 |
| 151 | 3115 5036 80 | G3115 5036 80 | COVER COMPL. | 1 |
| 152 | 3115 5036 10 | G3115 5036 10 | COVER | 1 |
| 160 | 0666 7190 01 | G0666 7190 01 | RADIAL LIP SEAL | 1 |
| 161 | 0335 2173 00 | G0335 2173 00 | CIRCLIP | 1 |
| 172 | 3115 5042 00 | G3115 5042 00 | FRONT PART | 1 |
| 174 | 3115 5044 05 | G3115 5044 05 | FLUSHING HEAD | 1 |
| 176 | 3115 5190 00 | G3115 5190 00 | CUP SEAL | 1 |
| 177 | 3115 5045 01 | G3115 5045 01 | GUIDE | 1 |
| 178 | 3115 3024 00 | G3115 3024 00 | WIPER | 1 |
| 180 | 3115 3245 00 | G3115 3245 00 | SEAL RING | 1 |
| 181 | 3115 3245 00 | G3115 3245 00 | SEAL RING | 1 |
| 184 | 3115 5059 00 | G3115 5059 00 | WASHER | 1 |
| 185 | 3115 5340 20 | G3115 5340 20 | STOP RING | 1 |
| 186 | 3115 5043 12 | G3115 5043 12 | CONNECT. PLATE | 1 |
| 187 | 3115 1825 00 | G3115 1825 00 | PLUG | 1 |
| 188 | 0147 1479 03 | G0147 1479 03 | SCREW, HEX HEAD | 2 |
| 189 | 3315 0195 10 | G3315 0195 10 | LOCK WASHER | 2 |
| 191 | 0102 0473 00 | G0102 0473 00 | PIN | 1 |
| 192 | 3115 3289 17 | G3115 3289 17 | SEAL RING | 3 |
| 193 | 0663 2143 00 | G0663 2143 00 | O-RING | 1 |
| 194 | 3115 3445 00 | G3115 3445 00 | SEAL RING | 1 |
| 195 | 0663 2145 01 | G0663 2145 01 | O-RING | 1 |
| 200 | - | - | GEAR HOUSING GR | 1 |
| 201 | 3115 5035 81 | G3115 5035 81 | GEAR HOUSING. ASSY. | 1 |
| 202 | 3115 5035 00 | G3115 5035 00 | GEAR HOUSING | 1 |
| 212 | 0544 2162 00 | G0544 2162 00 | GREASE NIPPLE | 1 |
| 214 | 0686 4201 03 | G0686 4201 03 | PLUG | 1 |
| 215 | 0653 9038 00 | G0653 9038 00 | GASKET | 1 |
| 217 | 0666 7188 01 | G0666 7188 01 | RADIAL LIP SEAL | 1 |
| 218 | 0335 2169 00 | G0335 2169 00 | CIRCLIP | 1 |
| 221 | 3115 3613 00 | G3115 3613 00 | STUD | 4 |
| 225 | 3115 0273 00 | G3115 0273 00 | WASHER | 1 |
| 231 | 3115 0821 00 | G3115 0821 00 | SHAFT | 1 |
| 232 | 0516 1504 01 | G0516 1504 01 | NEEDLE BEARING | 1 |
| 233 | 3115 0823 00 | G3115 0823 00 | WASHER | 1 |
| 234 | 3115 0274 00 | G3115 0274 00 | GEAR WHEEL | 1 |
| 235 | 0516 1538 00 | G0516 1538 00 | NEEDLE BEARING | 1 |
| 236 | 3115 0824 00 | G3115 0824 00 | SLEEVE | 1 |
| 237 | 0667 1206 00 | G0667 1206 00 | SEAL | 1 |
| 238 | 3115 2742 00 | G3115 2742 00 | GUIDE SLEEVE | 1 |
| 239 | 0663 2133 01 | G0663 2133 01 | O-RING | 1 |
| 250 | 3115 5313 80 | G3115 5313 80 | ROT.CHUCK,COMPL | 1 |
| 251 | 3115 5313 80 20 | G3115 5313 80 20 | ROT.CHUCK, Bare | 1 |
| 252 | 3115 1881 00 | G3115 1881 00 | CHUK.BUSH.GUIDE | 1 |
| 255 | 0509 0221 00 | G0509 0221 00 | ROLLER BEARING | 1 |
| 256 | 0509 0223 00 | G0509 0223 00 | ROLLER BEARING | 1 |
| 257 | 3115 0297 01 | G3115 0297 01 | SHIM | 1 |
| 258 | 3115 0297 02 | G3115 0297 02 | SHIM | 1 |
| 259 | 3115 0297 03 | G3115 0297 03 | SHIM | 1 |
| 260 | 3115 5314 00 | G3115 5314 00 | DRIVER | 1 |
| 261 | 3115 2968 01 | G3115 2968 01 | ROT.CH.BUSHING | 1 |
| 270 | 3115 3245 00 | G3115 3245 00 | SEAL RING | 1 |
| 271 | 0663 2120 00 | G0663 2120 00 | O-RING | 2 |
| 301 | 3115 5274 80 | G3115 5274 80 | INTERM. COMPL. | 1 |
| 302 | 3115 5274 22 | G3115 5274 22 | INTERMED. PART | 1 |
| 320 | 3115 5358 02 | G3115 5358 02 | LINER | 1 |
| 322 | 3115 3289 23 | G3115 3289 23 | SEAL RING | 1 |
| 324 | 3115 3289 13 | G3115 3289 13 | SEAL RING | 2 |
| 326 | 3115 5360 00 | G3115 5360 00 | DISK SPRING | 1 |
| 328 | 3115 1746 06 | G3115 1746 06 | NOZZLE | 3 |
| 340 | 3115 2384 00 | G3115 2384 00 | VALVE SEAT | 1 |
| 341 | 3115 3283 00 | G3115 3283 00 | VALVE CONE | 1 |
| 342 | 3115 3290 18 | G3115 3290 18 | SEAL RING | 1 |
| 345 | 3115 3455 00 | G3115 3455 00 | CONNECT. PLATE | 1 |
| 346 | 0211 1960 84 | G0211 1960 84 | SCREW | 2 |
| 347 | 0663 2100 62 | G0663 2100 62 | O-RING | 2 |
| 350 | 3115 2988 00 | G3115 2988 00 | SEAL RING | 2 |
| 352 | 3115 5146 01 | G3115 5146 01 | SEAL RING | 1 |
| 356 | 3115 1879 00 | G3115 1879 00 | SEAL KIT | 1 |
| 358 | 3115 1880 00 | G3115 1880 00 | SEAL KIT | 1 |
| 360 | 3115 2971 00 | G3115 2971 00 | DAMPING PISTON | 1 |
| 370 | 0686 9110 00 | G0686 9110 00 | PROTECTION PLUG | 1 |
| 401 | 3115 1944 80 | G3115 1944 80 | CYLINDER | 1 |
| 402 | 3115 1944 00 | G3115 1944 00 | CYLINDER | 1 |
| 415 | 3115 1165 00 | G3115 1165 00 | STUD | 4 |
| 416 | 3115 2112 00 | G3115 2112 00 | GUIDE | 1 |
| 420 | 3115 5275 80 | G3115 5275 80 | SEAL HOUSE COMP | 1 |
| 422 | 3115 0970 00 | G3115 0970 00 | SEAL KIT | 2 |
| 423 | 0663 2105 76 | G0663 2105 76 | O-RING | 1 |
| 425 | 3115 5050 01 | G3115 5050 01 | Piston Guide | 1 |
| 430 | 3115 3635 01 | G3115 3635 01 | PISTON | 1 |
| 435 | 3115 1680 00 | G3115 1680 00 | PISTON GUIDE | 1 |
| 440 | 3115 2772 80 | G3115 2772 80 | SEAL HOUSE COMP | 1 |
| 441 | 3115 2772 00 | G3115 2772 00 | SEAL HOUSING | 1 |
| 442 | 3115 1156 00 | G3115 1156 00 | SEAL KIT | 2 |
| 443 | 0663 6135 00 | G0663 6135 00 | O-RING | 1 |
| 445 | 3115 1765 00 | G3115 1765 00 | VALVE PISTON | 1 |
| 446 | 3115 2077 03 | G3115 2077 03 | VALVE COVER | 1 |
| 447 | 3115 2076 05 | G3115 2076 05 | VALVE COVER | 1 |
| 450 | 0147 1438 03 | G0147 1438 03 | SCREW, HEX HEAD | 4 |
| 455 | 3115 3291 00 | G3115 3291 00 | REG. PLUG | 1 |
| 456 | 3115 3214 00 | G3115 3214 00 | NUT | 1 |
| 457 | 3115 1697 00 | G3115 1697 00 | SEAL WASHER | 2 |
| 460 | 3115 3245 00 | G3115 3245 00 | SEAL RING | 1 |
| 470 | 0663 6134 01 | G0663 6134 01 | O-RING | 1 |
| 471 | 0663 6134 01 | G0663 6134 01 | O-RING | 1 |
| 475 | 0663 2133 01 | G0663 2133 01 | O-RING | 1 |
| 476 | 0663 2133 01 | G0663 2133 01 | O-RING | 1 |
| 501 | 3115 3481 00 | G3115 3481 00 | BACK HEAD | 1 |
| 505 | 0147 1481 03 | G0147 1481 03 | SCREW, HEX HEAD | 3 |
| 510 | 0663 6138 00 | G0663 6138 00 | O-RING | 1 |
| 0686 9250 26 | G0686 9250 26 | PLUG | 2 |
| 0686 9250 27 | G0686 9250 27 | PLUG | 2 |
| 3115 1603 91 | G3115 1603 91 | NIPPLE SET | 1 |
