| SN | Ref Part No. | Part No. | Descriptions | Qty. |
| 1 | 3121085100 | G3121 0851 00 | Drill Steel Retainer | 1 |
| 2 | 3121085200 | G3121 0852 00 | Retainer Pin | 1 |
| 3 | 108339200 | G0108 3392 00 | Tension Pin | 2 |
| 4 | 3121003000 | G3121 0030 00 | Rubber Buffer | 1 |
| 5 | 3121002900 | G3121 0029 00 | Buffer Plate | 1 |
| 6 | 3121029200 | G3121 0292 00 | Dome Nut | 2 |
| 7 | 3121034200 | G3121 0342 00 | Front Head | 1 |
| 8(9-11) | 3121076980 | G3121 0769 80 | Rotation Chuck, Comp. | 1 |
| 9 | 3121076900 | G3121 0769 00 | Rotation Chuck | 1 |
| 10 | 3121002300 | G3121 0023 00 | Rotation Chuck Bushing (H22X108) | 1 |
| 11 | 3115122100 | G3115122100 | Chuck Nut | 1 |
| 12 | 3121033900 | G3121 0339 00 | lntermediate Part | 1 |
| 13(14-15) | 3100847880 | G3100 8478 80 | Piston, Comp. | 1 |
| 14 | 3100847000 | G3100 8470 00 | Piston | 1 |
| 15 | 3100929905 | G3100 9299 05 | Rifle Nut | 1 |
| 16 | 3121033700 | G3121 0337 00 | Cylinder | 1 |
| 17 | 3115177800 | G3115177800 | Outlet Valve | 1 |
| 18 | 3115177900 | G3115177900 | Lever For Extra Blowing | 1 |
| 18 | 3006873400 | G3006 8734 00 | Conical Nut | 2 |
| 19 | 3106868300 | G3106 8683 00 | Guide Disc | 1 |
| 20 | 3106868200 | G3106 8682 00 | Ratchet Box | 1 |
| 21 | 108133600 | G0108133600 | Tension Pin | 1 |
| 22 | 3101315400 | G3101315400 | Rifle Bar | 1 |
| 23(24-26) | 3115920090 | G3115 9200 90 | Pawl, Complete | 1 |
| 24 | 3100914002 | G3100 9140 02 | Pressure Spring | 4 |
| 25 | 3100964101 | G3100 9641 01 | Plunger | 4 |
| 26 | 3101315900 | G3101315900 | Pawl | 4 |
| 27 | 3100966500 | G3100 9665 00 | Guide Pin | 1 |
| 28(29-30) | 3106868080 | G3106 8680 80 | Cover Comp. | 1 |
| 29 | 3106868000 | G3106 8680 00 | Valve Cover | 1 |
| 30 | 3100989401 | G3100 9894 01 | Cover Bush | 1 |
| 31 | 3106868100 | G3106 8681 00 | Main Valve | 1 |
| 32 | 3115056900 | G3115 0569 00 | Back Head | 1 |
| 33 | 3121034900 | G3121 0349 00 | Throttle Valve | 1 |
| 34 | 3115104500 | G3115104500 | Washer | 1 |
| 35 | 9000034500 | G9000 0345 00 | Adapter | 1 |
| 36 | 3115117000 | G3115117000 | Hose Nipple | 1 |
| 37 | 9000033300 | G9000 0333 00 | Coupling Nut | 1 |
| 38 | 3121032900 | G3121 0329 00 | Pin | 1 |
| 39 | 3111013600 | G31110136 00 | Coil Spring | 1 |
| 40 | 3121033200 | G3121 0332 00 | Lock Washer | 1 |
| 41 | 663212800 | G0663 2128 00 | O-ring | 1 |
| 42 | 3115057300 | G3115 0573 00 | Throttle Lever | 1 |
| 43 | 3006873400 | G3006 8734 00 | Nut | 1 |
| 44 | 3121137200 | G3121137200 | Handle Grip | 2 |
| 45 | 3000011901 | G3000 0119 01 | Washers | 2 |
| 46 | 3121029200 | G3121 0292 00 | Dome Nut | 2 |
| 47 | 3121034300 | G3121 0343 00 | Side Bolt | 1 |
| 48 | 3115057400 | G3115 0574 00 | Washer | 1 |
| 49 | 3121035200 | G3121 0352 00 | Air Flushing Tube | 1 |
| 50 | 3121033600 | G3121 0336 00 | Packing | 1 |
| 51 | 3000934102 | G3000 9341 02 | Sealing Washer | 1 |
| 52 | 3100962301 | G3100 9623 01 | Adapter | 1 |
| 53 | 3101414600 | G3101414600 | Sealing Washer (Big) | 1 |
| 54 | 3100964301 | G3100 9643 01 | Protective Nut | 1 |
| 55 | 3121036000 | G3121 0360 00 | Handle Bolt Complete With Dome Nut | 1 |
| 56 | - | - | Data Plate | 1 |
