| SN | OEM Part No | Part No. | Descriptions | Qty. |
| 1 | 3121 0583 00 | G3121 0583 00 | Front Head | 1 |
| 2 | 3121 0851 00 | G3121 0851 00 | Drill Steel Retainer | 1 |
| 3 | 3115 2925 00 | G3115 2925 00 | Retainer Pin | 1 |
| 4 | 3121 0029 00 | G3121 0029 00 | Buffer Plate | 1 |
| 5 | 3121 0030 00 | G3121 0030 00 | Buffer | 1 |
| 6 | 0108 3392 00 | G0108 3392 00 | Spring Pin | 2 |
| 7 | 3121 0872 00 | G3121 0872 00 | Side Bolt Nut | 2 |
| 8 (9-10) | 3121 0882 80 | G3121 0882 80 | Rotation Chuck, Complete | 1 |
| 9 | 3121 0882 00 | G3121 0882 00 | Rotation Chuck | 1 |
| 10 | 3121 0846 00 | G3121 0846 00 | Rotation Chuck Bushing | 1 |
| 11 | 3115 1313 00 | G3115 1313 00 | Chuck Nut | 1 |
| 12(12.1,12.2) | 3115 1837 80 | G3115 1837 80 | Ratchet Wheel, Complete | 1 |
| 12.1 | 3115 1837 00 | G3115 1837 00 | Ratchet Wheel | 1 |
| 12.2 | 3115 1838 00 | G3115 1838 00 | Rifle Nut | 1 |
| 13 (14-16) | 3115 9201 90 | G3115 9201 90 | Pawl, Complete | 1 |
| 14 | 3101 3159 00 | G3101 3159 00 | Pawl | 4 |
| 15 | 3121 0021 00 | G3121 0021 00 | Pawl Pin | 4 |
| 16 | 3121 0020 00 | G3121 0020 00 | Pawl Spring | 4 |
| 17 (18-20) | 3121 0580 80 | G3121 0580 80 | Intermediate Part, Complete | 1 |
| 18 | 3121 0580 00 | G3121 0580 00 | Intermediate Part | 1 |
| 19 | 3121 0581 00 | G3121 0581 00 | Bushing | 1 |
| 20 | 3121 0582 00 | G3121 0582 00 | Bushing | 1 |
| 21 | 3115 1694 00 | G3115 1694 00 | Piston | 1 |
| 22 (23-25) | 3121 0577 80 | G3121 0577 80 | Cylinder, Complete | 1 |
| 23 | 3121 0577 00 | G3121 0577 00 | Cylinder | 1 |
| 24 | 3121 0620 00 | G3121 0620 00 | Cylinder Liner | 1 |
| 25 | 0663 6142 00 | G0663 6142 00 | O-ring | 1 |
| 26 | 3121 0576 01 | G3121 0576 01 | Cover | 1 |
| 27 | 0663 2114 00 | G0663 2114 00 | O-ring | 1 |
| 28 | 3121 0900 00 | G3121 0900 00 | Guide Pin | 1 |
| 29 | 3121 0901 00 | G3121 0901 00 | Pressure Spring | 1 |
| 30 | 3121 0689 00 | G3121 0689 00 | Main Valve | 1 |
| 31 (32-53) | 3121 0571 81 | G3121 0571 81 | Back Head, Complete | 1 |
| 32 | 3121 0571 00 | G3121 0571 00 | Back Head | 1 |
| 33 (34-35) | 3121 0572 80 | G3121 0572 80 | Throttle Valve, Complete | 1 |
| 34 | 3121 0572 00 | G3121 0572 00 | Throttle Valve | 1 |
| 35 | 3121 0573 00 | G3121 0573 00 | Valve Liner | 1 |
| 36 | 3131 0107 00 | G3131 0107 00 | Coil Spring | 1 |
| 37 | 3121 0127 00 | G3121 0127 00 | Pawl Pin | 1 |
| 38 | 0663 2128 00 | G0663 2128 00 | O-ring | 1 |
| 39 | 3141 0001 00 | G3141 0001 00 | Lever | 1 |
| 40 | 3006 8734 00 | G3006 8734 00 | Conical Nut | 1 |
| 41 | 3121 0574 00 | G3121 0574 00 | Valve Pin | 1 |
| 42(43-52) | 3121 0551 80 | G3121 0551 80 | Valve Housing, Complete | 1 |
| 43 | 3121 0551 00 | G3121 0551 00 | Valve Housing | 1 |
| 44 | 0663 2126 00 | G0663 2126 00 | O-ring | 2 |
| 45 | 3100 9240 21 | G3100 9240 21 | Conical Spring | 1 |
| 46(47-48) | 3115 0982 80 | G3115 0982 80 | Valve Body, Complete | 1 |
| 47 | 3115 0982 00 | G3115 0982 00 | Valve Body | 1 |
| 48 | 0663 2112 00 | G0663 2112 00 | O-ring | 1 |
| 49 | 3121 0553 00 | G3121 0553 00 | Valve Pin | 1 |
| 50 | 0663 2120 00 | G0663 2120 00 | O-ring | 1 |
| 51 | 3121 0552 00 | G3121 0552 00 | Valve Seat | 1 |
| 52 | 0663 2120 00 | G0663 2120 00 | O-ring | 1 |
| 53 | 3121 0884 00 | G3121 0884 00 | Handle Bracket (left) | 1 |
| 54 | 3121 0885 00 | G3121 0885 00 | Handle Bracket (right) | 1 |
| 55 | 3121 0887 00 | G3121 0887 00 | Handle Grip | 1 |
| 56 | 0246 1302 00 | G0246 1302 00 | Stud | 1 |
| 57 | 3121 0883 00 | G3121 0883 00 | Nut | 2 |
| 58 | 3121 0679 00 | G3121 0679 00 | Side Bolt | 2 |
| 59 | 3121 0501 00 | G3121 0501 00 | Strainer | 1 |
| 60 | 3121 0545 00 | G3121 0545 00 | Packing | 1 |
| 61 | 3121 0010 00 | G3121 0010 00 | Adapter | 1 |
| 62 | 3100 9653 00 | G3100 9653 00 | Rubber Packing | 1 |
| 63 | 3100 9654 00 | G3100 9654 00 | Hose Nipple 12.5 mm (½”) | 1 |
| 64 | 3100 9652 00 | G3100 9652 00 | Adapter | 1 |
| 65 | 3121 0521 00 | G3121 0521 00 | Inlet Nipple | 1 |
| 66 | 0663 2128 00 | G0663 2128 00 | O-ring | 1 |
| 67 | 0517 1108 00 | G0517 1108 00 | Ball | 20 |
| 68 | 3121 0550 00 | G3121 0550 00 | Adapter | 1 |
| 69 | 3121 0595 00 | G3121 0595 00 | Pin | 1 |
| 70 | 3000 5825 03 | G3000 5825 03 | Adaptor | 1 |
| 71 | 9000 0326 00 | G9000 0326 00 | Hose Nipple 25 mm (1”) | 1 |
| 72 | 9000 0339 00 | G9000 0339 00 | Wing Nut | 1 |
| 73 | 3121 0776 00 | G3121 0776 00 | Guide Ring | 1 |
| 74 | 3100 9646 00 | G3100 9646 00 | Washer | 1 |
| 75 | 3121 0433 00 | G3121 0433 00 | Water Flushing Tube | 1 |
| 76 | 0663 2125 00 | G0663 2125 00 | O-ring | 1 |
| 77 | 3121 0575 00 | G3121 0575 00 | Adapter | 1 |
| 78 | 3121 0106 00 | G3121 0106 00 | Air Flushing Tube | 1 |
| 79 | 3000 0121 00 | G3000 0121 00 | Packing | 1 |
| 80 | - | - | Data Plate | 1 |
| | | | |
| SN | OEM Part No | Part No. | Descriptions | Qty. |
| 1(2-6) | 3122 0391 80 | G3122 0391 80 | Machine attachment kit | 1 |
| 2 | 3122 0391 00 | G3122 0391 00 | Machine attachment | 1 |
| 3 | 3122 0392 00 | G3122 0392 00 | Bolt | 1 |
| 4 | 3111 0136 00 | G3111 0136 00 | Spring | 1 |
| 5 | 0301 2378 00 | G0301 2378 00 | Washer | 1 |
| 6 | 0291 1128 25 | G0291 1128 25 | Lock nut | 1 |
