| SN | Symbol | Part No. | Description | QTY |
| 1 | # | GA2599 | Steel Retainer | 1 |
| 2 | # | GA1384 | Steel Retainer Pin | 1 |
| 3 | G12812UF (GD1932) | Steel Retainer Pin Nut | 1 | |
| 4 | @ | GD2050 | Bushing | 2 |
| 5 | GA2598A | Front Head | 1 | |
| 6 | ¤ | GSNB500 | Copper Gasket | 1 |
| 7 | GC1418A | Chuck Insert 22 mm | 1 | |
| 8 | # | GB1778 | Chuck | 1 |
| 9 | GC1516 | Spacer Chuck Nut | 1 | |
| 10 | GC1517 | Chuck Nut | 1 | |
| 11 | GE393 | Cylinder | 1 | |
| 12 | # | GC1323 | Cylinder Lug Bush | 1 |
| 13 | GD8345 | Plug | 1 | |
| 14 | ■ | GD1390 (GD2105) | Ferrule | 1 |
| 15 | GC1517 | Front Cylinder Liner | 1 | |
| 16 | GB2334 | Piston | 1 | |
| 17 | ! | GC1508 | Rifle Nut | 1 |
| 18 | GA744 | Valve Plug | 1 | |
| 19 | # | GC1648 | Valve | 1 |
| 20 | # | GA745 | Valve Box | 1 |
| 21 | GS2128 | Valve Box Pin | 1 | |
| 22 | # | GB1173R | Rifle Bar | 1 |
| 23 | $ | GD6177 | Ratchet Pawl | 4 |
| 24 | $ | GD6199 | Pawl Plunger | 4 |
| 25 | GD1611C | Pawl Spring | 4 | |
| 26 | # | GB1170 | Ratchet Ring | 1 |
| 27 | BA6668 | Throttle Jackleg | 1 | |
| 28 | GB1176 | Throttle Valve Jackleg | 1 | |
| 29 | # | GC1509 | Handle, Throttle Jackleg | 1 |
| 30 | # | GD1384 | Throttle Valve Key | 1 |
| 31 | # | G149163MT | Washer, Spring Disc | 1 |
| 32 | GD1385 | Throttle Valve Nut | 1 | |
| 33 | # | G8er5/8 | Throttle | 1 |
| 34 | GD1601 | Copper Washer | 1 | |
| 35 | ■ | G164731 (G1648114) | O Ring | 1 |
| 36 | GC1525N | Air Bend | 1 | |
| 37 | # | G1359588A | Hose Spud | 1 |
| 38 | G164999 (G164750A, G164521) | O Ring | 1 | |
| 39 | GS355538A | Air Filter | 1 | |
| 40 | GL05 | Oil Connection | 1 | |
| 41 | B+ | GC1809 | Stem, Water Threaded | 1 |
| 41 | B+ | GC1528 | Water Elbow (Ribbed) | 1 |
| 42 | GS2141 | Nut, Water Stem | 1 | |
| 43 | # | GS48F1W | Nut, Water Stem | 1 |
| 44 | ■ | G164811 (G1686503) | O-Ring | 8 |
| 45 | GS2487 | Thrust Washer | 1 | |
| 46 | # | GD1402 | Water Inlet Rubber | 1 |
| 47 | GC1272 | Water Inlet Screen | 1 | |
| 48 | # | GD2441 | Nut (Adapter) | 1 |
| 51 | GD1383 | Throttle Valve Plunger | 1 | |
| 52 | GD1382 | Throttle Plunger Spring | 1 | |
| 53 | G2422P | Plug, Throttle Detent | 1 | |
| 54 | ■ | GC1574A G164231 (G1643903) | Water Tube | 6 |
| 55 | ■ | GD1675 | Water Tube Seal | 1 |
| 56 | GD1674 | Water Tube Spring | 1 | |
| 57 | ■ | GC2144 | Water Valve Seat Retainer | 1 |
| 58 | ■ | GD1673 | Water Valve Seat | 1 |
| 59 | WB1181PC4 | Water Control Valve Body | 1 | |
| 60 | ■ | G1648102 | O Ring | 1 |
| 61 | GC1522PC1 (G1648102) | Water Control Valve | 1 | |
| 62 | GC1522PC1 | O Ring | 1 | |
| 63 | ■ | G164521 (G164750A, G164521) | O Ring | 1 |
| 64 | # | GD1488 | Spring | 1 |
| 65 | GC1521PC1 | Spring Cap | 1 | |
| 66 | G20015/G20029MM | Internal Circlip | 1 | |
| 67 | GC1560 | Throttle Jackleg | 1 | |
| 68 | Side rod nut open | 2 | ||
| 69 | GD1388D | Side rod nut open | 2 | |
| 70 | GD2984 | Spring | 2 | |
| 71 | GC3844 | Guide assembly handle | 1 | |
| 72 | G12812UF | Nylon nut M20 | 2 | |
| 73 | GD3188D | Side rod nut | 2 | |
| 74 | GD2154 | Adapter | 1 | |
| 75 | # | GB1729 | Fronthead lifting handle | 1 |
| 76 | GB3352 | Handle bar | 1 | |
| 77 | GS21205 | Grip for JH handle | 1 | |
| 78 | GD2340 | Cylinder lug bush | 2 | |
| 79 | GC1939 | Bush backhead lug | 2 | |
| 80 | ■ | GD1454 | Nyloc nut 3/4 UNF | 1 |
| 81 | GA6492 | Throttle operating handle | 1 | |
| 82 | G1643403 | O Ring | 1 | |
| 83 | # | G164731(G1648116) | O Ring | 1 |
| 84 | # | GL05 | Air Connection | 1 |
| 85 | GL07 | Lubricator | 1 | |
| 86 | #GFILL07 | Filter | 1 | |
| 87 | # | GRB1141 | Nut | 2 |
| 88 | GL06 | Adapter | 1 | |
| 89 | ## | GL-08 | Lubricator Outlet Connection | 1 |
| 90 | ¤ | GAHG250 | Air Hose Connection | 1 |
| 91 | ## | GWHG250 | Water Hose Connection | 1 |
